Bench drill with laser 13 mm

£129.99
|
Delivery Time 6-9 working days
OUT OF STOCK
SKU
4252023109178
Product Image

Powerful
The robust steel construction with the powerful 500 watt motor delivers plenty of power and ensures accurate drilling results. With built-in vibration-damping,the machine will run very smoothly. The column drill also impresses with its great price-performance ratio!

Product Image 2

Integrated position laser
You can achieve particularly accurate, millimetre-precise drilling results thanks to the integrated position laser. Use laser points, laser crosses and laser lines individually or in combination to position workpieces, components or other objects. Shape, position and prominent geometric features will all be taken into account.

Product Image 3

Stable stand for your safety
Thanks to the stable column design with a large 42 x 21 cm base plate, controlled drilling processes are child's play. In addition, the base is provided with elongated holes for attachment to a conventional vise.

Product Image 4

High-quality 13 mm sprocket drill chuck
In contrast to other drills, AREBOS does not use a quick-action chuck, but instead relies on a high-quality gear rim drill chuck. This is much stronger and more stable. It also makes it possible for you to work with various kinds of materials, even metal.

Product Image 5

Tiltable drilling table
The maximum distance between the 164 x 162 mm work table and the drill chuck is 175 mm. This distance can be reduced continuously. In addition, the drill table can be tilted 45° to either side. To do this, loosen the hexagonal bolt underneath the table, set the desired angle and tighten the bolt again.

Product Image 6

2-in-1: Height-adjustable work table
You can choose between two ways of clamping the workpiece. You can fix it either on the height-adjustable table or on the base plate. Made of robust steel, the bench drill convinces with high torsional rigidity and a long service life.

Product Image 7

Includes a vise as standard!
The vise included in the delivery scope makes working with this 2-in-1 machine even more comfortable. It enables optimum adjustment of the drill settings to the material being drilled.

Product Image 7

5 variable speed settings
The variable speed control is used for optimum speed adjustment for the workpiece that needs to be machined. It is carried out manually, simply and without tools. The 5-stage speed adjustment from 550 to 2500 rpm allows targeted adaptation to different materials and surfaces.

SKU
4252023109178
Weight
2,769.00 kgs
Color
Red
Colour Corpus
Red
Delivery Scope
  • 1x Bench drill with laser
  • 1x Vice
  • 1x 13 mm gear rim drill chuck
  • 1x Instruction manual
Relevance of Dangerous Goods
No
Special Features
  • Extras: integrated laser, vice, 13 mm gear rim drill chuck
Brand
Arebos
Drilling Table Height
590 cm
Drilling Table Length
440 cm
Length Footplate
45 cm
Material
cast iron
Max. Distance to Base Plate
260 mm
Max. Distance Table
175 cm
Max. Inclination Angle Drilling Table
45 °
Model Name
AR-HE-TBM13
Number of Packages
1
Number of Speed Levels
5
Sound Pressure Level dB(A)
68.4 dB
Power
500 W
Sound Power Level
78.8 dB
Table Size
164 x 162 mm
Type of Power Supply
Mains Connection
Uncertainty ( K )
3 dB
Wide Footplate
260 cm
Width Drilling Table
164 cm
Product Family
Bench Drill
